pump without inbuilt relief valve and flange mounted

Rotary Pumps

Series : pump without inbuilt relief valve and flange mounted

	Qty	Product Code	Model	Pump - Flow Rate	Pump Mounting	Inlet port size	Outlet port size	Max Output Pr	Reversible	L-Bracket	In-Built Relief Valve	Motor Rating Required
		C00101S00001	RP1F-14	1 litres/min	Flange	1/4" BSP	1/4" BSP	15 Bar	No	No	No	0.25 HP
		C00101S00002	RP3F-14	3 litres/min	Flange	1/4" BSP	1/4" BSP	15 Bar	No	No	No	0.25 HP
		C00101S00003	RP4F-14	4 litres/min	Flange	1/4" BSP	1/4" BSP	15 Bar	No	No	No	0.5 HP
		C00101S00004	RP4F-38	4 litres/min	Flange	3/8" BSP	3/8" BSP	15 Bar	No	No	No	0.5 HP
		C00101S00005	RP6F-14	6 litres/min	Flange	1/4" BSP	1/4" BSP	15 Bar	No	No	No	0.5 HP
		C00101S00006	RP6F-38	6 litres/min	Flange	3/8" BSP	3/8" BSP	15 Bar	No	No	No	0.5 HP
		C00101S00007	RP10F-12	10 litres/min	Flange	1/2" BSP	1/2" BSP	15 Bar	No	No	No	1 HP
		C00101S00008	RP16F-12	16 litres/min	Flange	1/2" BSP	1/2" BSP	15 Bar	No	No	No	1 HP
		C00101S00009	RP25F-12	25 litres/min	Flange	1/2" BSP	1/2" BSP	15 Bar	No	No	No	1.5 HP
		C00101S00010	RP40F-12	40 litres/min	Flange	1/2" BSP	1/2" BSP	15 Bar	No	No	No	1.5 HP
		C00101S00011	RP1F-14-Rev	1 litres/min	Flange	1/4" BSP	1/4" BSP	15 Bar	Yes	No	No	0.25 HP
		C00101S00012	RP3F-14-Rev	3 litres/min	Flange	1/4" BSP	1/4" BSP	15 Bar	Yes	No	No	0.25 HP
		C00101S00013	RP4F-14-Rev	4 litres/min	Flange	1/4" BSP	1/4" BSP	15 Bar	Yes	No	No	0.5 HP
		C00101S00014	RP4F-38-Rev	4 litres/min	Flange	3/8" BSP	3/8" BSP	15 Bar	Yes	No	No	0.5 HP
		C00101S00015	RP6F-14-Rev	6 litres/min	Flange	1/4" BSP	1/4" BSP	15 Bar	Yes	No	No	0.5 HP
		C00101S00016	RP6F-38-Rev	6 litres/min	Flange	3/8" BSP	3/8" BSP	15 Bar	Yes	No	No	0.5 HP
		C00101S00017	RP10F-12-Rev	10 litres/min	Flange	1/2" BSP	1/2" BSP	15 Bar	Yes	No	No	1 HP
		C00101S00018	RP16F-12-Rev	16 litres/min	Flange	1/2" BSP	1/2" BSP	15 Bar	Yes	No	No	1 HP
		C00101S00019	RP25F-12-Rev	25 litres/min	Flange	1/2" BSP	1/2" BSP	15 Bar	Yes	No	No	1.5 HP
		C00101S00020	RP40F-12-Rev	40 litres/min	Flange	1/2" BSP	1/2" BSP	15 Bar	Yes	No	No	1.5 HP
